Description
LiDAR
- Laser Wavelength: 905nm ±15nm
- Eye Safety Rating: CLASS 1 (IEC 60825-1:2014)
- Detection Range: 0.05–50m (90% reflectivity); 0.1–25m (10% reflectivity)
- Minimum Detection Distance: 0.05m
- Field of View (FOV): Horizontal: 360°; Vertical: -10° to 60°
- Point Cloud Accuracy: 1 cm (Relative); 3 cm (Absolute)
- Sampling Rate: >200kHz
- Point Cloud Output: 154,600 pts/s @ 70° vertical FOV
Electrical & Interface
- Charging: 5V / 3A
- Battery: 3.6V / 6,700mAh
- Power Consumption: <5W (at 25℃)
- Charging Time: ≤ 3 hours
- Operating Time: ≥ 5 hours
- Data Port: USB 3.0
- Charging/Data Port: USB 2.0
- Firmware Upgrade: OTA (Over-the-Air)
Compatibility & Physical
- Mobile: iPhone 15 & later (iOS)
- Dimensions: 137 × 155 × 250 mm
- Weight: Approx. 890g
- Mounting: 5/8″ internal threaded
- Operating Temperature: -10℃ to 60℃
- Charging Temperature: 0℃ to 45℃
